User-Friendly SMART3 Colorimeter for Water Analysis in Field or Laboratory

Fiyat Sorunuz

Portable SMART3 Colorimeter with 75+ pre-programmed test programs, multiple LED optical system, and 500-point data logger. IP67 waterproof with USB connectivity.

IP67 Waterproof rating
Large graphic liquid crystal display
Simple, menu-driven operation
Alphabetic test selection
75+ pre-programmed tests
Rechargeable lithium-ion battery or computer/wall adapter power
500 data-point data logger with timestamp
25 user-defined test programs
Backlit display for field readability
Auto shut-off function
USB Mini B connection
CE marked for European compliance
Superior narrow-bandwidth interference filters
Super Twist backlit LCD for enhanced readability
Optional software for data storage and processing

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

The SMART3 Colorimeter is an intuitive water analysis instrument designed for both field and laboratory use. Featuring easy-to-use software with over 75 pre-programmed test programs compatible with LaMotte reactive systems, the device automatically selects the optimum wavelength from a multiple LED optical system for each sample reaction. Results are displayed on a large, backlit liquid crystal screen in concentration units, Absorbance values, or % T readings. Users can enter up to 25 additional calibrations for specialized reactive systems, with test factors adjustable across three sequences to accommodate changing analytical requirements. The integrated data logger stores up to 500 timestamped data points, while USB connectivity enables real-time data collection and computer interface for data transfer. Powered by a rechargeable lithium-ion battery or external adapter.

Technical Specifications

Display	160 x 100 backlit LCD, 20 x 6 line graphic display
Wavelengths	428 nm, 525 nm, 568 nm, 635 nm
Wavelength Accuracy	±2% FS
Wavelength Bandwidth	10 nm typical
Photometric Range	-2 to +2 AU
Photometric Sensitivity	±0.001 AU at 1.0 AU
Photometric Accuracy	±0.005 AU at 1.0 AU
Light Sources	4 LEDs
Detectors	4 integrated silicon photodiodes with parasitic filters
Measurement Modes	Pre-programmed tests, Absorbance, % T
Languages	English, Spanish, French, Portuguese, Italian, Chinese, Japanese
Sample Chamber	25 mm diameter flat-bottom test tubes, 10 mm square cuvettes, 16 mm COD tubes
USB Connection	Mini B
Power Source	Rechargeable lithium-ion battery 3.7V, 2.5 x 0.75 inch, 1.7 oz OR USB computer cable OR wall adapter
Battery Life	Charge Duration: Approximately 380 tests with backlight on, 1000 tests with backlight off (signal averaging disabled). Battery Lifespan: Approximately 500 charges
Auto Shut-Off Options	Disabled, 5, 10, 50 minutes
Dimensions	8.84 x 19.05 x 6.35 cm; 3.5 x 7.5 x 2.5 inches
Weight	362 g; 13 oz
Shipping Dimensions	29.2 x 27.9 x 11.43 cm; 11.5 x 11 x 4.5 inches
Shipping Weight	1.18 kg; 4 lbs

Applications

Portable water quality analysis for field sampling
Laboratory colorimetric water testing
Environmental monitoring and compliance testing
Drinking water analysis
Wastewater treatment plant monitoring
Swimming pool and recreational water testing
Industrial process water analysis
Research and educational applications
Real-time data collection with computer interface

Frequently Asked Questions

How many pre-programmed test methods are available?

The SMART3 Colorimeter includes over 75 pre-programmed test programs that are pre-configured for LaMotte reactive systems, allowing immediate use without manual setup.

Can custom test methods be added?

Yes, users can input up to 25 additional calibrations for specialized reactive systems, enabling customization beyond the pre-programmed options.

How is the colorimeter powered?

The device can be powered by a rechargeable lithium-ion battery (3.7V), a USB computer cable, or a wall adapter, providing flexibility for laboratory and field use.

What is the data storage capacity?

The integrated data logger stores up to 500 timestamped data points, which can be transferred to a computer via USB connection.

Is the instrument suitable for field use?

Yes. The SMART3 is IP67 waterproof rated, features a backlit display for field readability, and operates on battery power, making it suitable for both field and laboratory applications.

What wavelengths does the instrument measure?

The SMART3 operates at four wavelengths: 428 nm, 525 nm, 568 nm, and 635 nm, automatically selecting the optimal wavelength for each test.

What is the photometric accuracy?

Photometric accuracy is ±0.005 AU at 1.0 AU, with sensitivity of ±0.001 AU at 1.0 AU and a measurement range of -2 to +2 AU.

Is software included for data management?

Optional software is available for data storage and processing. USB connectivity enables real-time data collection and computer interface integration.
