INNO Microplate Spectrophotometer (Absorbance)

Fiyat Sorunuz

Next-generation monochromator-based microplate reader for absorbance measurements from 200-999 nm

Monochromator-based optical system for free wavelength selection (200-999 nm)
Supports 6 to 384-well microplate formats
Photodiode detector with xenon flash light source
Dynamic range: 0-4.0 OD with ±1% accuracy and repeatability
Wavelength accuracy: ±2 nm
Multiple measurement modes: Wavelength Scanning, Endpoint, Kinetic, Area Scan
Optional DNA/RNA/Protein (NANO-V) microplate module (24-well, 2 µL sample)
Dual-speed linear and orbital shaking functions
Comprehensive Windows software (INNO X) with advanced curve fitting

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

The INNO Monochromator Spectrophotometer (Absorbance) is a cutting-edge instrument designed for modern research laboratories requiring single-wavelength absorbance measurements. Built on advanced monochromatic optical measurement technology, the INNO elevates your research capabilities with precise wavelength selection from 200 nm to 999 nm. The system accommodates 6 to 384-well microplates and is ideal for routine molecular biology assays, protein quantification, nucleic acid analysis, and comprehensive spectroscopic applications.

Technical Specifications

Wavelength Accuracy	±2 nm
Microplate Format	6 to 384-well plates
Detector Type	Photodiode
Light Source	Xenon flash
Wavelength Range	200 – 999 nm
Wavelength Selection	Monochromator-controlled
Measurement Modes	Wavelength Scanning, Endpoint, Kinetic, Area Scan
Dynamic Range	0 – 4.0 OD
OD Accuracy	0 – 2 OD ±1%
OD Linearity	0 – 2 OD ±1%
OD Repeatability	0 – 2 OD ±1%
Shaking Function	Linear and orbital (dual-speed control)
Optional NANO-V Module	24-well microplate, 2 µL sample volume
Weight / Dimensions	7.5 kg / 333 × 303 × 245 cm
Software Platform	INNO X (Windows-based)
Curve Fitting Options	Linear, Quadratic, Cubic, Log, Exponential, Linear logarithmic, Point-to-point, 4PL

Applications

Routine molecular biology and biochemistry assays
Protein quantification and analysis
Nucleic acid concentration determination
Enzyme kinetics studies
Cell viability and proliferation assays
ELISA and immunoassay applications
Microbial growth monitoring
Spectrophotometric wavelength scanning studies

Frequently Asked Questions

What wavelength range does the INNO support?

The INNO provides continuous wavelength selection from 200 to 999 nm through its monochromator-based optical system, with ±2 nm accuracy.

Which microplate formats are compatible?

The INNO accommodates microplates ranging from 6-well to 384-well formats, providing flexibility for various experimental scales.

What is the typical OD measurement accuracy?

The system delivers ±1% accuracy, linearity, and repeatability across the 0-2 OD range within a 0-4.0 OD dynamic range.

Is the optional DNA/RNA/Protein module available?

Yes, the optional NANO-V microplate module is available, featuring a 24-well format requiring only 2 µL sample volumes, ideal for precious samples.

What measurement modes does the INNO offer?

The INNO supports Wavelength Scanning, Endpoint, Kinetic, and Area Scan measurement modes to accommodate diverse experimental protocols.

What are the data analysis capabilities?

The INNO X software provides multiple curve fitting regression models including Linear, Quadratic, Cubic, Log, Exponential, Linear logarithmic, Point-to-point, and 4-parameter logistic (4PL).
