ELISA Plate Reader LTek

Fiyat Sorunuz

Advanced 4-wavelength bichromatric optical ELISA plate reader with 8-channel fiber optic system for high-throughput microplate analysis

4-wavelength bichromatric optical detection system
8-channel fiber optic sensor array
Complete plate reading in 5 seconds
55 configurable assay calculation modes
Large 320 x 240 LCD touchscreen display
Windows-based operating system with modem connectivity for software updates
500 test protocol + 10,000 result memory capacity
Variable temperature and speed mixer
RS-232 and parallel port data interfaces
External printer support

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

The LTek ELISA Plate Reader is a sophisticated microplate analyzer designed for automated immunoassay and biochemical analysis. Featuring a dual-wavelength bichromatric optical detection system with 8-channel fiber optic technology, it delivers rapid plate scanning with complete 96-well plate readout in 5 seconds. The instrument combines Windows-based software control with an intuitive 320 x 240 LCD touchscreen interface, offering flexible data entry options via touchscreen or external mouse input. With memory capacity for 500 test protocols and 10,000 results, integrated data management, and standard laboratory interfaces, the LTek is ideal for clinical diagnostics, research laboratories, and quality control applications.

Technical Specifications

Microplate Compatibility	Standard 96-well microtiter plate or strip wells
Linear Measurement Range	0.000 – 3.200 Abs
Calculation Modes	55 different program modes
Wavelengths	405, 450, 490, 630nm standard + blank filter
Repeatability (CV)	±1%
Light Source	Tungsten halogen lamp
Mixer	Adjustable time and speed parameters
Display	320 x 240 LCD
Data Input	Touchscreen or external mouse
Printer Connection	External printer interface
Memory Capacity	500 test protocols + 10,000 results
Communication Interfaces	RS-232 and parallel port
Processor	RISC processor
Power Requirements	260VAC, 60Hz
Origin	Belgium

Applications

Clinical diagnostic immunoassays (ELISA, sandwich assays)
Enzyme-linked immunosorbent testing
Protein quantification and biomarker detection
Microbial and pathogen identification
Pharmaceutical compound screening and QC
Research and development laboratories
Quality control and validation testing
Colorimetric assay analysis

Frequently Asked Questions

What is the reading speed of the LTek plate reader?

The LTek can read a complete standard 96-well microplate in 5 seconds, providing rapid throughput for high-volume testing environments.

Which wavelengths are supported?

The instrument includes standard wavelengths of 405, 450, 490, and 630nm, plus a blank filter for reference measurements.

What is the measurement accuracy?

The LTek maintains a repeatability coefficient of variation (CV) of ±1% across the linear measurement range of 0.000 – 3.200 Abs.

Can I store assay protocols and results?

Yes, the instrument has memory capacity for 500 test protocols and 10,000 result datasets for later review and analysis.

Is data transfer available?

The LTek includes RS-232 and parallel port interfaces for data transfer to external computers and peripheral devices. Software updates are supported via modem connection.

What assay modes are available?

The instrument offers 55 different calculation program modes to accommodate various assay methodologies and result formats.
