Atago PAL-pH Digital Handheld pH Meter

Atago PAL-pH is a compact digital pH meter designed for minimal sample volume applications. The device delivers pH measurements in the 0.00-14.00 range with ±0.10 pH accuracy and is specifically optimized for challenging samples such as amine-based cutting fluids.

With its unique drop-type design, the PAL-pH requires only 0.6 ml of sample for measurement, enabling significant sample conservation in situations with limited sample availability or during high-throughput testing. Three-point calibration (4.01/6.86/9.18 or 4.01/7.00/10.01) ensures compatibility with various buffer solution standards. Automatic temperature compensation (10-40°C) minimizes measurement drift caused by ambient temperature variations.

Powered by 2×AAA alkaline batteries, the device provides portability for both field and benchtop laboratory applications. Designed for laboratories and manufacturing facilities seeking a practical solution for quality control in food and beverage production, soil analysis, water-soluble cutting oils, and alkaline cleaning solution verification.

Note: This device does not carry IP65 water/dust protection certification; additional precautions are recommended when used in humid or dusty environments.

Technical Specifications

Applications

• pH control in food and beverage manufacturing
• pH measurement in soil samples
• pH monitoring of water-soluble cutting oils
• Quality control of alkaline cleaning solutions
