UC 22-MF Multifrequency Ultrasonic Cleaning System | Hydra Ultrasonic

Fiyat Sorunuz

Advanced multifrequency ultrasonic cleaner for precision components in electronics, medical, and optical applications

Multifrequency technology: 40 kHz, 80 kHz, and 120 kHz selectable frequencies
Dual-capability system for deep cleaning and surface integrity preservation
Automatic frequency switching for optimized cleaning performance
22-liter capacity with AISI 304 stainless steel construction
Digital control panel with adjustable parameters (1-99 minutes, 1-80°C)
High-efficiency ultrasonic transducers with 480W effective power
600W high-durability ceramic heating element
Ideal for precision components: electronics, medical devices, optical equipment

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

The UC 22-MF is a professional-grade ultrasonic cleaning system engineered for high-precision surface cleaning of sensitive components in electronics, medical devices, and optical equipment. Featuring three selectable frequency options up to 120 kHz, it provides exceptional flexibility for diverse contamination types and material surfaces. Advanced frequency switching technology optimizes cleaning efficacy while preserving component surface integrity, enabling both deep cavitation cleaning and delicate surface treatment in a single unit.

Technical Specifications

Tank Volume	22 liters
Tank Dimensions (L×W×H)	500 × 300 × 150 mm
Basket Inner Dimensions (L×W×H)	450 × 230 × 100 mm
External Dimensions (L×W×H)	560 × 320 × 320 mm
Power Supply	230V – 50/60Hz
Ultrasonic Power	480W effective / 960W peak
Heater Power	600W (high-durability ceramic element)
Operating Frequencies	40 kHz, 80 kHz, 120 kHz (multifrequency)
Frequency Switching	Automatic
Ultrasonic Transducers	High-efficiency design
Operating Time Range	1-99 minutes (adjustable)
Temperature Control Range	1-80°C (adjustable)
Control Interface	Digital control panel
Tank & Housing Material	AISI 304 stainless steel (complete)
Basket Material	Stainless steel
Lid Material	Stainless steel
Drain System	½" outlet

Applications

Precision cleaning of electronic circuit boards and components
Medical instrument and surgical tool sterilization cleaning
Optical lens and optical system component cleaning
Jewelry and luxury goods surface treatment
Metal parts decontamination and surface preparation
Dental and laboratory equipment maintenance
Automotive precision component cleaning

Frequently Asked Questions

What are the advantages of multifrequency technology?

Multifrequency operation (40 kHz, 80 kHz, 120 kHz) allows automatic adjustment to different component types and contamination levels. Lower frequencies provide deeper cavitation action for stubborn soils, while higher frequencies deliver gentler cleaning to preserve delicate surfaces.

Is the UC 22-MF suitable for sensitive optical components?

Yes. The system's advanced frequency control and stainless steel construction enable safe, effective cleaning of optical components without surface damage, while maintaining high cleaning standards.

What is the cleaning capacity?

The 22-liter tank with 450 × 230 × 100 mm basket dimensions provides ample capacity for most precision components, while the compact footprint suits laboratory and industrial environments.

How is temperature controlled?

A 600W ceramic heating element provides precise temperature control within the 1-80°C range, allowing optimization for specific cleaning chemistry and material requirements.

What is the automatic frequency switching feature?

Automatic frequency switching optimizes cleaning parameters throughout the operation cycle, ensuring consistent results across varying contamination profiles without manual intervention.

Is the system easy to maintain?

Yes. AISI 304 stainless steel construction offers excellent corrosion resistance, and the ½" drain system allows quick solution changes and system maintenance.
