Single Manifold Membrane Filtration System

Fiyat Sorunuz

Complete membrane filtration system for precise microorganism detection in drinking water, process water, and beverage samples with stainless steel single manifold configuration

Single manifold stainless steel design for efficient membrane filtration operations
Large sample volume capability for enhanced detection sensitivity
Powerful vacuum pump (18 LT/min) for rapid filtration
Complete integrated system with accessories
Suitable for drinking water, process water, and beverage analysis
High-quality cellulose nitrate filter media for optimal microorganism retention

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

Membrane filtration is a highly effective analytical method for sensitive detection and quantification of microorganisms in drinking water, process water, and various beverages. This system enables processing of sample volumes larger than conventional 1-2 ml protocols, delivering high detection rates even when microorganism counts are minimal in test samples. The membrane filtration method relies on microorganism retention on an analytical filter membrane. The fundamental principle involves passing a defined sample volume through the membrane filter and subsequently inoculating the filter onto culture medium. The filter's pore size is smaller than microorganism dimensions, ensuring reliable capture of target organisms. After filter placement onto appropriate culture medium and incubation, resulting colonies are enumerated and evaluated.

Technical Specifications

Manifold	DRVAC-130 Stainless Steel Single Manifold
Vacuum Pump	DRVAC-300, 18 LT/min
Tubing	PL023.01.1608 Silicone Tubing, 16 mm / 8 mm, 2.00 m
Collection Vessel	PL028.01.02000 Suction Bottle, 2000 ml
Filter Media	LF006.01.0047 Cellulose Nitrate Filter Paper, Sartorius, 47 mm, 0.45 µm
Marking Pen	FC100-30 Filter Marking Pen Set

Applications

Drinking water microbiological analysis and monitoring
Process water quality control and verification
Beverage industry quality assurance testing
Environmental water sampling and analysis
Pathogenic microorganism detection in liquid samples
Regulatory compliance testing for water safety standards

Frequently Asked Questions

What is the minimum sample volume that can be processed?

Unlike conventional methods limited to 1-2 ml samples, this membrane filtration system accommodates larger sample volumes, enabling superior detection sensitivity for low-count microorganism populations.

What is the pore size of the filter media?

The cellulose nitrate filter media (LF006.01.0047) has a 0.45 µm pore size, designed to retain microorganisms while allowing fluid passage.

How long does the filtration process take?

Filtration speed depends on sample volume and characteristics; the 18 LT/min vacuum pump (DRVAC-300) provides rapid, efficient processing.

Is this system suitable for beverage testing?

Yes, the system is specifically designed for microorganism detection in drinking water, process water, and various beverages including carbonated drinks.

What are the maintenance requirements?

Regular filter replacement and periodic cleaning of stainless steel components are recommended. The silicone tubing should be inspected for wear and replaced as necessary.
