Analitik Terazi Radwag AS 510.3Y (510gr)

Stoklu siparişleriniz aynı gün kargoda!

AS Series Analytical Balances

Fiyat Sorunuz

Professional analytical balances with 5.7″ touchscreen display, customizable user profiles, and advanced weighing applications for laboratory environments.

5.7" resistive color touchscreen with intuitive interface
Internal automatic calibration with internal reference mass
RADWAG patented LevelSENSING balance monitoring system
Real-time environmental condition monitoring (internal sensors or external THB 2 module)
Large weighing chamber for protection against air currents
Customizable user profiles for application-specific configurations
Interactive formula database for mixture preparation
Multi-mode weighing for process control over time
Extended data management: storage, printing, and transfer capabilities
Class I OIML classification

Compare

Add to wishlist

Kargolama ve Teslimat

Kurye Teslimatı

Kuryemiz belirtilen adrese teslimat yapacaktır.

2-3 Gün

Ü.A. Kargo

Aras Kargo Teslimatı

Aras Kargo kuryesi belirtilen adrese teslimat yapacaktır.

1-3 Gün

Ücretsiz Kargo

Garanti 2 yıl

Daha fazla detay

14 Günlük ücretsiz iade

Daha fazla detay

The AS.3Y Series analytical balances feature a 5.7" TFT full-color touchscreen interface with freely configurable user profiles, enabling detailed parameter customization for sophisticated customer-specific applications. The balance system is equipped with an internal automatic calibration mechanism utilizing internal reference masses, with real-time balance monitoring through RADWAG's patented LevelSENSING electronic system. Environmental conditions can be monitored in real-time via integrated sensors or the external THB 2 environmental conditions module. The large weighing chamber provides protection against air currents and maintains sterile, clean measurement conditions. Interactive formula execution and database support ensure speed and reliability during sample preparation. Extended data management capabilities allow users to store, print, and transfer measurement results. The balance supports multiple weighing modes for process weight control over time and includes comprehensive calibration and verification features.

Technical Specifications

Maximum Capacity [Max]	310 g
Minimum Load	10 mg
Readability [d]	0.1 mg
Tare Range	-310 g
Repeatability (5% Max)	0.08 mg
Repeatability (Max)	0.15 mg
Linearity	±0.3 mg
Minimum Weight (U = 1%, k = 2)	16 mg
Minimum Weight (USP)	160 mg
Stabilization Time	3.5 s
Calibration	Internal (automatic)
OIML Class	I
Display	5.7 inch resistive color touchscreen
Communication Interfaces	2 × RS232, 2 × USB-A, Ethernet, 4 Digital I/O, Wi-Fi®
Power Supply	100 ÷ 240 V AC 50/60 Hz
Power Consumption (Max)	7 W
Operating Temperature	+10 ÷ +40 °C
Weighing Pan Diameter	ø100 mm
Packaging Dimensions	600 × 400 × 540 mm
Net Weight	6.2 kg
Gross Weight	11 kg

Applications

Analytical chemistry and pharmaceutical research
Quality control and assurance in laboratories
Mixture and formulation preparation
Precision sample weighing for calibration verification
Compliance with USP and OIML Class I standards
Environmental monitoring-dependent weighing applications
Process control over multiple measurement cycles
Educational and research institutions

Frequently Asked Questions

What is the maximum weighing capacity of the AS.3Y series?

The AS.3Y analytical balance has a maximum capacity of 310 g with a readability of 0.1 mg, making it suitable for precision analytical applications.

How does the LevelSENSING system work?

The patented LevelSENSING electronic system continuously monitors the balance condition in real-time, ensuring accurate measurements by compensating for environmental influences.

Can environmental conditions be monitored automatically?

Yes, the AS.3Y can monitor temperature and humidity in real-time using integrated sensors or the optional external THB 2 environmental conditions module.

Is the calibration process automatic?

The balance features an internal automatic calibration system utilizing internal reference masses, simplifying maintenance and ensuring measurement reliability.

What communication interfaces are available?

The balance includes 2 × RS232, 2 × USB-A, Ethernet, 4 Digital I/O connections, and Wi-Fi® connectivity for flexible data transfer and integration.

Are user profiles customizable?

Yes, the AS.3Y offers freely configurable user profiles allowing detailed parameter customization for application-specific and customer-specific configurations.

What weighing modes are available?

The balance supports multiple weighing modes including interactive formula execution with database support for mixture preparation and process weight control over time.

What is the stabilization time?

The AS.3Y achieves measurement stabilization in approximately 3.5 seconds, enabling rapid analytical workflows.
